Коммутатор Ruckus ICX7150-24F-4X1G

Артикул:

ICX7150-24F-4X1G

298 116 ₽

3900$

Курс ЦБ 76.44
на

Нашли дешевле?

Гарантия 12 месяцев

- +

В корзину

Купить в 1 клик

Пообщаться с менеджером

Цена действительна только для интернет-магазина и может отличаться от цен в розничных магазинах

Сравнить

Избранное

Загрузить в pdf

Описание

Характеристика

Ruckus ICX 7150 Compact Switch, 12×10/100/1000 Mbps PoE+ ports, 2×1 GbE RJ45 uplink-ports, 2×1 GbE SFP
uplink-ports upgradable to 2×10 GbE SFP+ with license. 124 W PoE budget, basic Layer 3 (static routing and RIP)

Switching capacity (data rate, full duplex)	68 Gbps
Forwarding capacity (data rate, full duplex)	51 Mpps
10/100/1000 Mbps RJ45 downlinks	12
10/100/1000 Mbps RJ45 uplinks (full duplex only, no PoE)	2
1/10 Gbps SFP/SFP+ uplinks	2
PoE/PoE+ ports	12
Maximum PoE Class 3 ports (15.4 W per port)	8
Maximum PoE+ Class 4 ports (30 W per port)	4
Base IPv4/v6 Layer 3 routing3 (static routing, RIP)	Yes
Advanced IPv4/v6 Layer 3 routing3 (OSPF, VRRP, PIM, PBR features)	With license
Aggregated stacking bandwidth3 (data rate, full duplex)	240 Gbps
Stacking density3 (maximum switches in a stack)	12
Stacking ports3 (maximum ports4 usable for stacking)	Up to 2×10 GbE SFP+
Maximum stacking distance3 (distance between stacked switches)	10 km
Power inlet (AC)	C14
Input voltage/frequency	AC: 100 to 240 VAC @ 50 to 60 Hz
Power supply rated maximum (AC)	150 W
PoE power budget (AC)	124 W
Airflow	Fanless
Net Weight (Kg)	2.58
Dimensions (mm)	269 (W) 213 (D) 43.4 (H)
Acoustics (25°C, min fan speed)	Fanless
MTBF (25°C)	562,889 hours
Connector options	• 10/100/1000 Mbps RJ-45 • 1 Gbps SFP ports • 1/10 Gbps SFP+ ports • Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45 • Console management: RJ45 serial port and USB Type-C port with serial communication device class support • File transfer: USB port, standard-A plug
DRAM NVRAM (Flash) Packet buffer size	• 1 GB • 2 GB • 12/24 port: 2 MB, 48 port: 4 MB
Maximum MAC addresses	• 16,384
Maximum VLANs Maximum PVLANs	• 4,095 • 32
Maximum STP (spanning trees instances)	• 254
Maximum VEs	• 128
Maximum ARP entries	• 4,094
Maximum routes (in hardware)	• 1,000 (IPv4), 1,000 (IPv6) • Next hop address: 4,094
Trunking	• Maximum ports per trunk: 16 • Maximum trunk groups: 128
Maximum jumbo frame size	• 9,216 bytes
QoS priority queues	• 8 per port
Multicast groups	• 3,072 (Layer 2) • 2,048 (Layer 3)
Quality of Service (QoS)	• ACL Mapping and Marking of ToS/DSCP (CoS) • ACL Mapping and Marking of 802.1p • ACL Mapping to Priority Queue • Classifying and Limiting Flows Based on TCP Flags • DiffServ Support • Honoring DSCP and 802.1p (CoS) • MAC Address Mapping to Priority Queue • Priority Queue Management using Weighted Round Robin (WRR), Strict Priority (SP), and a combination of WRR and SP
Traffic management	• ACL-based inbound rate limiting and traffic policies • Broadcast, multicast, and unknown unicast rate limiting • Inbound rate limiting per port • Outbound rate limiting per port and per queue
Security	• 802.1X authentication • MAC authentication • Flexible authentication • Web authentication • DHCP snooping • Dynamic ARP inspection • Neighbor Discovery (ND) Inspection • Bi-level Access Mode (Standard and EXEC Level) • EAP pass-through support • IEEE 802.1X username export in sFlow • Protection against Denial of Service (DoS) attacks • Authentication, Authorization, and Accounting (AAA) • MAC Address Locking MAC Port Security • Advanced Encryption Standard (AES) with SSHv2 • RADIUS/TACACS/TACACS+ • Secure Copy (SCP) • Secure Shell (SSHv2) • Local Username/Password • Change of Authorization (CoA) RFC 5176 • Trusted Platform Module
SDN features	• OpenFlow v1.0 and v1.3 • OpenFlow with hybrid port mode • Operates with an OpenDayLight Controller
High availability	• Layer 3 VRRP/VRRP-E protocol redundancy3 • Real-time state synchronization across the stack3 • Hitless failover and switchover from master to standby stack controller3 • Hot insertion and removal of stacked units3 • Layer 2 VSRP switch redundancy3 • In Service Software Update (ISSU)3
Layer 2 feature set	• 802.1s Multiple Spanning Tree • 802.1x Authentication • Auto MDI/MDIX • BPDU Guard, Root Guard • Dual-Mode VLANs • MAC-based VLANs, Dynamic MAC-based VLAN activation • Dynamic VLAN Assignment • Dynamic Voice VLAN Assignment • Fast Port Span • GVRP: GARP VLAN Registration Protocol • IGMP Snooping (v1/v2/v3) • IGMP Proxy for Static Groups • IGMP v2/v3 Fast Leave • Inter-Packet Gap (IPG) adjustment • Link Fault Signaling (LFS) • MAC Address Filtering • MAC Learning Disable • MLD Snooping (v1/v2) • Multi-device Authentication • Per-VLAN Spanning Tree (PVST/PVST+/PRST) • Mirroring: Port-based, ACL-based, MAC Filter-based, and VLAN-based • PIM-SM v2 Snooping • Port Loop Detection • Private VLAN • Remote Fault Notification (RFN) • Single-instance Spanning Tree • Trunk Groups (static, LACP) • Uni-Directional Link Detection (UDLD) • Metro-Ring Protocol (MRP) (v1, v2) • Virtual Switch Redundancy Protocol (VSRP)3 • Q-in-Q • Topology Groups
Base Layer 3 IP routing3 feature set	• IPv4 and IPv6 static routes • RIP v1/v2, RIPng • ECMP • Port-based Access Control Lists • Layer 3/Layer 4 ACLs • Host routes • Virtual Interfaces • Routed Interfaces • Route-only Support • Routing Between Directly Connected Subnets
Premium Layer 3 IP routing3 feature set with software license	• IPv4 and IPv6 dynamic routes • OSPF v2, v3 • PIM-SM, PIM-SSM, PIM-DM, PIM passive (IPv4, IPv6) • PBR • Virtual Route Redundancy Protocol VRRP (IPv4) • VRRP v3 (IPv6) • VRRP-E (IPv4/IPv6)
IEEE standards compliance	• 802.1AB LLDP/ LLDP-MED • 802.1D MAC Bridging • 802.1p Mapping to Priority Queue • 802.1s Multiple Spanning Tree (MST) • 802.1w Rapid Reconfiguration of Spanning Tree (RSTP) • 802.1x Port-based Network Access Control (PNAC) • 802.3 Carrier Sense Multiple Access/Collision Detection (CSMA/CD) • 802.3ab 1000BASE-T • 802.3 10Base-T • 802.3ad Link Aggregation (Dynamic and Static) • 802.1 AX-2008 Link Aggregation • 802.3ae 10 Gigabit Ethernet • 802.3af Power over Ethernet • 802.3at Power over Ethernet Plus • 802.3bz Multigigabit Ethernet • 802.3u 100Base-TX • 802.3x Flow Control • 802.3z 1000Base-SX/LX • 802.3 MAU MIB (RFC 2239) • 802.1Q VLAN Tagging • 802.1BR Bridge Port Extension3
Management	• DHCP Auto Configuration • Configuration Logging • Digital Optical Monitoring • Display Log Messages on Multiple Terminals • Embedded Web Management (HTTP/HTTPS) • Embedded DHCP Server • Industry-standard Command Line Interface (CLI) • Brocade Network Advisor (sold separately) • CLI activation of optional software features • Integration with HP OpenView • USB file management and storage • Macro for batch execution • Out-of-band Ethernet Management • TFTP • TELNET Client and Server • SSH / SSH V2 • Bootp • SNMPv1/v2c • DHCP Server and DHCP Relay • SNMPv3 Intro to Framework • Architecture for Describing SNMP Framework • SNMP Message Processing and Dispatching • SNMPv3 Applications • SNMPv3 User-based Security Model • SNMP View-based Access Control Model SNMP • sFlow • Network Time Protocol (NTP) • Multiple Syslog Servers • SCP • Virtual Cable Tester (VCT)3
Ruckus Campus Fabric technology3	• The Ruckus ICX 7150 can operate in fabric Port Extender (PE) mode • Up to 36 PEs per fabric (up to 1800 ports) • PE cascade depth up to 6 units
Temperature	Operating temperature: -5°C to 45°C Storage temperature: −25°C to 70°C
Humidity	Operating relative humidity: 5% to 95% at 45°C, non-condensing Non-operating relative humidity: 0% to 95% at 70°C, non-condensing
Altitude	Operating altitude: 10,000 ft (3,000 m) maximum Storage altitude: 39,000 ft (12,000 m) maximum
